The OdourClean Dispenser is a simple, gravity-fed unit designed to continuously deliver cleaning and deodorising fluid into urinals or WCs, tackling odours at the source while reducing bacteria build-up.

Every drip helps eliminate offensive smells and minimises surface stains, maintaining a fresher, more hygienic washroom environment with minimal effort.

With no motors or batteries, the OdourClean is a low-maintenance, cost-effective solution - ideal for budget-sensitive contracts or sites with limited servicing access.

Its reliable, automatic operation ensures washrooms stay clean and welcoming between service visits, providing washroom service companies with an efficient, fuss-free option for maintaining washrooms.

• Delivery System: Gravity-fed drip.
• Fluid Compatibility: Works with Unicorn Hygienics’ cleaner & deodoriser liquids.
• Refill Size: Compatible with 25L liquid refills.
• Material: Durable ABS plastic construction.
• Installation: Wall-mounted; suitable for urinals and WCs.
• Dimensions: [Insert height × width × depth].
• Power Requirements: None – fully gravity-operated.

Our OdourClean 25L refills are a cleaner and deodoriser. Specially formulated for use with the OdourClean dispenser, it helps to prevent bacteria build-up and eliminate unpleasant odours, leaving your washroom clean and fresh with every dose.

What You’ll Need:

• OdourClean dispenser unit

• Wall fixings and screws (included)

• Drill and screwdriver

• A pencil for marking

• OdourClean refill solution

• Water for dilution

1. Choose Installation Location

• Select a position above or near the urinal or WC where gravity can allow the fluid to drip directly into the bowl.

• Ensure the surface is clean, dry, and free from dust or grease.

• Recommended height: approx. 1.2 – 1.4m from floor level.

2. Mark Drill Points

• Open the dispenser to access the back plate.

• Use the integrated spirit level on the dispenser to ensure it is positioned straight.

• Mark the fixing points through the mounting holes using a pencil.

3. Drill and Fix

• Drill holes at the marked points and insert wall plugs (if fixing into masonry or tile).

• Secure the back plate to the wall using the supplied screws.

4. Fill the Dispenser

• Remove the internal bottle from the dispenser.

• Pour in the OdourClean refill solution, then dilute with water according to your preferred dosage level (refer to instructions on the refill drum).

• Replace the filled bottle inside the dispenser.

5. Prime the System

• Ensure the drip nozzle is securely in place.

• Open the valve (if applicable) to allow the fluid to begin feeding through.

• Confirm the fluid is dripping correctly into the urinal or WC.

6. Close and Secure

• Close the dispenser cover until it clicks into place.

• The unit is now fully operational.

Maintenance Tips:

• Refill the internal bottle as needed based on usage.

• Check the drip rate regularly to ensure consistent performance.

• Clean the nozzle periodically to prevent blockages or residue build-up.
